PSR 488DG DUAL BALL BEARING TURBO BILLET COMPRESSOR WHEEL

1.070,99 € – 1.784,99 €

inkl. MwSt. zzgl. Versandkosten

CNC Machined Aluminum?Bearing Housing with The?FIN COOLING DESIGN
G series design 9 Blade?Inconel 713 turbine wheel for improved gas flow ability and reduced turbo lag
Dual Ceramic Ball Bearing Systems
Billet Compressor Wheels with Extended Tip Technology
-12AN Oil Drain Flange and TRB. Inlet Gasket Come in Box

Lieferzeit: 3-7 Werktage

Compressor Housing Options

Turbine Housing Options

Zurücksetzen

Beschreibung

Recommending Engine Displacement: 3.0-8.0L

HP Rating 750-1550

Features:

CNC Machined Aluminum Bearing Housing with The FIN COOLING DESIGN
G series design 9 Blade Inconel 713 turbine wheel for improved gas flow ability and reduced turbo lag
Dual Ceramic Ball Bearing Systems
Billet Compressor Wheels with Extended Tip Technology
-12AN Oil Drain Flange and TRB. Inlet Gasket Come in Box

Details:

Compressor Wheel: 88*117mm 7+7 Blade
Compressor Inlet: 5.5” Slip-Fit
Compressor Outlet: V-band
Turbine Wheel: 96*88mm 9 Blade
Turbine Housing A/R: 1.15, 1.25, 1.32, 1.45, and 1.58 in Option
Turbine Housing Inlet & Outlet: T4 Divided Inlet, V-band Outlet; T6 Divided Inlet, 3/4 Marmon Outlet
Oil Feed Port 1/4NPT
Oil Drain Std T6 drain Flange

* V-band Flange Kits are available:

Compressor Housing Options	Without Compressor Cover, T51R MOD, Standard
Turbine Housing Options	Without Turbine Housing, T4(Divided) 1.25 A/R, T6(Divided) 1.15 A/R, T6(Divided) 1.32 A/R, T6(Divided) 1.45 A/R, T6(Divided) 1.58 A/R
