272 Degree street/strip performance cams. No cylinder head clearancing required. Can run stock valve spring up to 7500rpm and 1bar of boost.
 |
|||||||
| Engine Make: | Engine Model: | Part Number: | |||||
| NISSAN | RB25 NEO | 244-A2 | |||||
| Valve Clearance: | Intake: | 0.25mm | Set | COLD | at the | CAM | |
| Exhaust: | 0.30mm | Set | COLD | at the | CAM | ||
| Cam Lift: | Intake: | 9.20mm | Exhaust: | 9.20mm | |||
| Rocker Ratio: | Intake: | 1 | Exhaust: | 1 | |||
| Nett Valve Lift: | Intake: | 8.95mm | Exhaust: | 8.90mm | |||
| Advertised Duration @ | 0.10mm | Intake: | 264 | Exhaust: | 272 | ||
| Duration @ | 1.00mm VALVE LIFT | Intake: | 226 | Exhaust: | 234 | ||
| Timing @ | 1.00mm VALVE LIFT | IVO: | EVO: | 51 BBDC | |||
| IVC: | EVC: | 3 ATDC | |||||
| Suggested Centre Lines: | Intake: | VARI | Exhaust: | 114 | |||
| VALVE | Lift @ TDC | Intake: | Exhaust: | 1.20 | |||
