6870E Ball Bearing Turbo UP to 1100HP

1.011,49 € – 1.725,49 €

inkl. MwSt. zzgl. Versandkosten

Ball bearing system provides optimal turbo response & better durability by reducing the shaft-motion
Billet Compressor Wheel with Extended Tapered Tip Technology
Inconel 713c 10 Blade Turbine Wheel
V-Band Flange kit for the exhaust housing included
Max Engine Horsepower: 1100
The T51R MOD compressor cover is on backorder for two weeks.
This listing is on backorder until the end of April.

Lieferzeit: 3-7 Werktage

Compressor Cover Option

Turbine Housing Option

Zurücksetzen

Art.-Nr.: N/A Tags : 6870, 6870e, Ball Bearing Turbo, pte

Beschreibung

Billet Compressor Wheel: 68/92.46mm, 7+7 Blade
Turbine Wheel: 78.8 / 70.2mm, 10 Blade
Bearing System: Dual Ball Bearing (provides optimal turbo response & better durability by reducing the shaft-motion)
Compressor Cover Inlet/Outlet: 4.0” / 2.5” Hose
Turbine Housing: T4 Divided 1.0A/R (3″ V-band Outlet), T4 open 0.81A/R (3″ V-band Outlet)
The internal oil feed port is 0.9mm(Oil restrictor is no needed)
Oil feed fitting: 1/8-27 NPSF(Drawing)
Oil drain: T4 flange(Drawing)
Oil Drain Fitting:

10AN_STD

10AN_EXTENDED

Compressor Cover Option	Standard, Without compressor housing, T51R MOD
Turbine Housing Option	T4 open, Vband outlet, 0.81A/R, T4 Divided, Vband outlet, 1.0A/R, Without turbine housing, Dual V-band 0.96A/R
