Stage 1/1+/1.5/1.5+ Upgrade Gauge Controller

Stage 1/1+/1.5/1.5+ Upgrade Gauge Controller

105,77

Introducing the Water Methanol Injection Gauge Controller by Bosphorus Innovations. This innovative device combines a boost gauge, water-methanol controller, and fail-safe system in one compact unit. Equipped with a built-in 10 bar (145 psi) manifold absolute pressure sensor, the controller allows precise adjustment of water-methanol injection at desired boost levels to meet your engine’s specific requirements.
The dual-tone LCD screen (white and red) displays boost pressure (psi/bar/kpa/mpa), injection status, test mode, fault codes, response time, resolution, fine adjustment, power-saving mode, key lock, and output modes on a bright, easy-to-read display.
Upgrade your Stage 1 or 1+ water-methanol kit to Stage 1.5 or 1.5+. This gauge can also replace the display in 1.5 or 1.5+ water-methanol kits. Compatible with other brands’ kits as a controller (relay may be required).

Technical Features:
Working Temperature: -4°F to 176°F (-20°C to 80°C)
Switching Frequency: 2.5 milliseconds (1000 Hz)
Maximum Pressure: 174 psi (12 Bar)
Adjustment Accuracy: 0.2 Bar
Maximum Current: 0.2A
Voltage Rating: 9-32 Volt
6mm hose connection
Included Components:
Dash Gauge
5mm – 1/4″ (6mm) elbow hose fitting
6.5 ft (2m) wiring loom
