Make |
Nissan |
|
Model |
RB30/RB26DETT |
|
Part Number |
SC7301 |
|
Cylinders |
6 |
|
Bore (in) |
3.386 |
|
Bore (mm) |
86 |
|
Size |
STD |
|
Stroke |
85 |
|
Conrod |
152.5 |
|
Comp Height (in) |
1.28 |
|
Comp Height (mm) |
32.5 |
|
Dom/Dish CC |
0 |
|
Compression Ratio |
8.2 FT |
|
Weight (Grams) |
334 |
|
Pin (mm) |
21 |
|
Rings |
CPN-3386 |
|
Ring Thickness |
1.0 x 1.2 x 2.8mm |
|
Pin included (Standard) |
827-2250-20CP1C |
|
Upgraded Pin |
827-2250-20CP3C |
|
Ultra Duty Pin |
827-2250-25CP3C |
|
Locks |
827×063 SWL |
CP pistons are compatible with oversized valves and high lift camshafts. CP Pistons represent the highest quality and is engineered for maximum power. Standard features include: Deep valve reliefs accommodate high lift camshafts; Larger valve reliefs for +1mm valve sizes; Custom skirt cam and barrel design; Accumulator grooves; High strength aluminum forgings; High performance rings; Fully CNC machined and balanced to +/- 1 gram; Wrist pins included at no additional cost; Double pin oilers force fed from oil ring groove; Pin lock grooves for easy lock removal; Pin fitting included.
